OpenBSD-5.3

How-To : Vpn IKEv2 between a Windows 8 Road Warrior Host and an OpenBSD gateway

Considering the following network ...



Please, first read the man pages : IKED(8), IKED.CONF(5), PFCTL(8) and PF.CONF(5)

For newbies, OpenBSD FAQ, AFTERBOOT(8), RC.CONF(8), are useful

** IKED is not yet finished. **



:: The Gateway Part ::

hostname : vpn.domain.local

lan : 192.168.0.53/24

egress : static ip address provided by ISP : aa:bb:cc:dd

rl0 : group lan

rl1 : group egress



Sample to assign a network card(rl0) to a group "lan"

Edit the file /etc/hostname.rl0 and add this line :

!/sbin/ifconfig rl0 group lan



Install zip package for an easy export



export PKG_PATH=ftp://ftp.openbsd.org/pub/OpenBSD/5.1/packages/$(uname -m)/

pkg_add zip



Configure PF



Be sure that  "net.inet.ip.forwarding=1" # /etc/sysctl.conf

Or apply it on the fly : sysctl net.inet.ip.forwarding=1



/etc/pf.conf :



admin="ww.xx.yy.zz"

set skip on {lo,enc0}

match out on egress from lan:network to any nat-to egress

block log all

pass in on egress proto tcp from $admin to any port ssh

pass in on egress proto udp from any to any port {isakmp,ipsec-nat-t}

pass in on egress proto {ah,esp}

pass out on egress

pass on lan



We allow the host "ww.xx.yy.zz" to administrate the box using ssh (from the web)



Enable and load the rules

/sbin/pfctl -evf /etc/pf.conf



Get a custom ikeca.cnf to keep things as simply as possible



Get it here, and move it in /etc/ssl

or follow this :



cd /tmp

ftp ftp://ftp.openbsd.org/pub/OpenBSD/5.3/src.tar.gz

tar -C /usr/src -zxf src.tar.gz

cp /usr/src/usr.sbin/ikectl/ikeca.cnf /etc/ssl



Now, modify it at your convenience

Here a sample :

...

CERT_C                  = FR

CERT_ST                 = NA

CERT_L                  = REUNION

CERT_O                  = .aise

CERT_OU                 = VPN

CERT_CN                 =

CERT_EMAIL              = wesley@mouedine.net

...



Create certificates



/usr/sbin/ikectl ca vpn create # Common Name = Hostname

/usr/sbin/ikectl ca vpn install



/usr/sbin/ikectl ca vpn certificate aa.bb.cc.dd create #SERVER, CN = aa.bb.cc.dd

/usr/sbin/ikectl ca vpn certificate aa.bb.cc.dd install



/usr/sbin/ikectl ca vpn certificate windows create #CLIENT, CN = Name it at your convenience

/usr/sbin/ikectl ca vpn certificate windows export



Copy the windows.zip file on the win8 host.



Configure iked



/etc/iked.conf :



ikev2 passive esp \

from 192.168.0.0/24 to 10.10.10.0/24 local aa.bb.cc.dd peer any \

srcid aa.bb.cc.dd \

config address 10.10.10.7



You can start iked manually with : /sbin/iked



To have iked daemon at startup :

echo iked_flags= >> /etc/rc.conf.local



For testing purpose : /sbin/iked -dvv



View established connections :



# ipsecctl -sa

FLOWS:

flow esp in from 10.10.10.0/24 to 192.168.0.0/24 peer w8.w8.w8.w8 srcid IPV4/aa.bb.cc.dd type use

flow esp out from 192.168.0.0/24 to 10.10.10.0/24 peer w8.w8.w8.w8 srcid IPV4/aa.bb.cc.dd type require

flow esp out from ::/0 to ::/0 type deny



SAD:

esp tunnel from w8.w8.w8.w8 to aa.bb.cc.dd spi 0x1704e5e0 auth hmac-sha1 enc aes-256

esp tunnel from aa.bb.cc.dd to w8.w8.w8.w8 spi 0x55ace81c auth hmac-sha1 enc aes-256





:: Configure the win8 host ::

Windows 8 host : Dynamic Ip address provided by ISP (w8.w8.w8.w8)

IP address (ikev2) : 10.10.10.7



Import certificates



Use mmc / Certificates snap (computer account)/ import ca.pfx in "trusted root certification authorities"

Use mmc / Certificates snap (computer account)/ import windows.pfx in "Personal"



Create the VPN connection



IP (destination) : aa.bb.cc.dd

Type ikev2 / NO EAP / Only Certificate (check it !)

Configure IPv4 to 10.10.10.7



Tested with Microsoft Windows 7 & 8

Enjoy! ;-)



Thank's to the mailling list misc@openbsd.org

Especially : Mike Belopuhov and Pavel Shvagirev
